TP-Link CPE510 5GHz 300Mbps 13dBi Wireless Outdoor CPE (White)

... is ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi
coverage applications. Professional performance, coupled with
user-friendly design, makes CPE510 an ideal choice for both business and
home users. With Qualcomm Atheros enterprise level chipsets, high gain
antennas and high quality material, specially designed enclosure, and PoE
power supply, CPE510 is specially designed for outdoor use and can operate
flawlessly in almost any climate, with operating temperatures ranging from
-30? to +70. Built-in High Gain Dual-Polarized Antenna and dedicated metal
reflection ensures higher gain and lower noise interference. In advanced,
high power Tx (up to 27dBm/500mw) and high sensitivity Rx (up to -95dBm)
radio front-end design breaks down the barriers of traditional Wi-Fi
transmission range, making CPE510 an ideal product for outdoor wireless
networking applications. CPE510 is designed to work in harsh environments,
even in some of the world's most hostile climate conditions. With its
outdoor weatherproof enclosure and industrial-level hardware design,
CPE510 can continue operating in various weather conditions, such as
sunshine, rainfall, wind, snow or extremely low/high temperature
environment. Besides its grounding terminal, CPE510 offers another way to
eliminate ESD attacks via the PoE adapter and Ethernet cable with
grounding wire. The CPE510's additional security measures provide up to
15KV ESD and 6000V lightning protection for more reliable operation.As
network scale increases, wireless competition and collisions among CPEs
and base stations will be so enormous that the real throughput of the
network will drop, resulting in a serious impact on end-user experience,
to mitigate these effects, the CPE510 uses MAXtream TDMA Technology.
Specially designed for outdoor uses, ideal for long distance wireless data
transmission over 15km+, tested in the field. CPE510 also comes equipped
with centralized management software that helps users easily manage all
the devices in their network from a single PC - Pharos Control. Functions
like device discovery, status monitoring, firmware upgrading, and network
maintenance can be managed using Pharos Control. User-friendly web-based
management system allows professionals to apply more specific
configurations.



Features



Built-in 13dBi 2x2 dual-polarized directional MIMO antenna



Adjustable transmission power from 0 to 27dBm/500mw



System-level optimization for more than 15km long range wireless
transmission



Centralized Management System - Pharos Control



AP / Client / Repeater / AP Router / AP Client Router (WISP) operation
modes



Outdoor stabilized enclosure with IPX5 waterproof certification



Dual Ethernet ports and grounding terminal integrated



6000V Lightning Protection, 15KV ESD Protection



Passive PoE Adapter supports up to 60 meters (200 feet) power over
Ethernet deployment and allows for device reset remotely



Provides WEP, WPA/WPA2, WPA-PSK/WPA2-PSK data security



Selectable bandwidth of 5/10/20/40MHz



Provides Throughput Monitor, Spectrum Analyser, Speed Test and Ping
tools



Easy antenna alignment with wireless signal quality indicators via Web
interface



In The Box



Outdoor Wireless CPE



24V 1A Passive PoE Adapter



Pole Mounting Straps



AC Power Cord



Installation Guide



Extra Info



Main Colour: White
